24AA04T-I/OT Electronic Component Chips Original Integrated Circuit

Features

• Single Supply with Operation down to 1.7V for 24AA04 and 24FC04 Devices, 2.5V for 24LC04B Devices

• Low-Power CMOS Technology: - Read current 1 mA, maximum - Standby current 1 µA, maximum (I-temp.)

• Two-Wire Serial Interface, I2C Compatible

• Schmitt Trigger Inputs for Noise Suppression

• Output Slope Control to Eliminate Ground Bounce

• 100 kHz, 400 kHz and 1 MHz Compatibility

• Page Write Time: 5 ms, Maximum

• Self-Timed Erase/Write Cycle

• 16-Byte Page Write Buffer

• Hardware Write-Protect

• ESD Protection >4,000V

• More than 1 Million Erase/Write Cycles

• Data Retention >200 Years

• Factory Programming Available

• RoHS Compliant

• Temperature Ranges: - Industrial (I): -40°C to +85°C - Extended (E): -40°C to +125°C

• Automotive AEC-Q100 Qualified.

Description The Microchip Technology Inc. 24XX04(1) is a 4-Kbit Electrically Erasable PROM (EEPROM). The device is organized as two blocks of 256 x 8-bit memory with a two-wire serial interface. Its low-voltage design permits operation down to 1.7V with standby and active currents of only 1 µA and 1 mA, respectively. The 24XX04 also has a page write capability for up to 16 bytes of data.

Product name:24AA04T-I/OT
Manufacturer: Microchip	Product Category: Electrically Erasable Programmable Read-Only Memory
Installation style: SMD/SMT	Package / Case: SOT-23-5
Interface Type: 2-Wire, I2C	Storage capacity: 4 kbit
Organization: 512 x 8	Supply Voltage - Min: 1.7 V
Supply Voltage - Maximum: 5.5 V	Minimum operating temperature: - 40 C
Maximum operating temperature: + 85 C	Maximum clock frequency: 400 kHz
Access time: 3.5 us	Data retention: 200 Year
Supply Current—Maximum: 3 mA	Series: 24AA04
Brand: Microchip Technology	Height: 1.3 mm
Length: 3.1 mm	Operating supply current: 3 mA
Operating Supply Voltage: 1.8 V to 5.5 V	Product Type: EEPROM
Programming Voltage: 1.7 V to 5.5 V	Factory Packing Quantity: 3000
Subcategory: Memory & Data Storage	Width: 1.8 mm
Unit weight: 23 mg	Package: Reel Package: Cut Tape Package: MouseReel
