Electronic components IC 24LC02B-I/P Electrically Erasable Programmable Read Only Memory

Features

• Single Supply with Operation down to 1.7V for 24AA02 and 24FC02 Devices, 2.5V for 24LC02B Devices • Low-Power CMOS Technology: - Read current 1 mA, maximum - Standby current 1 µA, maximum (I-temp.)

• Two-Wire Serial Interface, I2C Compatible

• Schmitt Trigger Inputs for Noise Suppression

• Output Slope Control to Eliminate Ground Bounce

• 100 kHz, 400 kHz and 1 MHz Compatibility

• Page Write Time: 5 ms, Maximum

• Self-Timed Erase/Write Cycle

• 8-Byte Page Write Buffer • Hardware Write-Protect

• ESD Protection >4,000V • More than 1 Million Erase/Write Cycles

• Data Retention >200 Years • Factory Programming Available

• RoHS Compliant

• Temperature Ranges: - Industrial (I): -40°C to +85°C - Extended (E): -40°C to +125°C • Automotive AEC-Q100 Qualified

Description The Microchip Technology Inc. 24XX02(1) is a 2-Kbit Electrically Erasable PROM (EEPROM). The device is organized as one block of 256 x 8-bit memory with a two-wire serial interface. Its low-voltage design permits operation down to 1.7V with standby and active currents of only 1 µA and 1 mA, respectively. The 24XX02 also has a page write capability for up to 8 bytes of data.

Product name:24LC02B-I/P
Manufacturer: Microchip	Product Category: Electrically Erasable Programmable Read-Only Memory
Mounting Style: Through Hole	Package/Case: PDIP-8
Interface Type: 2-Wire, I2C	Storage capacity: 2 kbit
Organization: 256 x 8	Supply Voltage - Min: 2.5 V
Supply Voltage - Maximum: 5.5 V	Minimum operating temperature: - 40 C
Maximum operating temperature: + 85 C	Maximum clock frequency: 400 kHz
Access time: 900 ns	Data retention: 200 Year
Supply Current—Maximum: 3 mA	Series: 24LC02B
Package: Tube	Brand: Microchip Technology
Height: 3.3 mm	Operating Supply Voltage: 2.5 V to 5.5 V
Factory Packing Quantity: 60	Unit weight: 1 g
